AMF Panel Overview

AMF panels, also known as automatic mains failure panels, are used to provide automatic backup power during power outages. When a power outage is detected, an AMF panel or controller disconnects the main power supply and starts a standby generator. Once the main power supply is restored, the AMF panel shuts down the generator and transfers the load back to the main supply. AMF panels are frequently used in industrial settings where a continuous power supply is critical .

Technical Features of AMF Panels

Detection and Generator Activation:

AMF panel design is made to detect a loss of main power and automatically start a standby generator. When the main power supply fails, the AMF panel disconnects the main supply and starts the generator, transferring the load to the generator output.

Control and Monitoring Capabilities:

These panels include features like auto/manual selectors for switching between operation modes, timers for controlling generator start/stop delays, and emergency stop switches for safety.

Safety Protections:

AMF panels come equipped with protections such as low lube oil pressure (LLOP) cutoff, high water temperature protection, and fail-to-start alarms to ensure the safe operation of the generator.

Monitoring and Annunciation:

AMF panels provide visual (LED) indications and audible (hooter) alarms for various conditions, including mains status, generator status, LLOP, high water temperature, and start failures.

Customization:

AMF controllers can be customized with different configurations and features (like manual overrides and fault monitoring) to meet specific requirements and applications.

Specification	Details	General Values	Possible Values
Rated Voltage	Nominal operating voltage of the AMF panel	415V AC	230V, 415V AC
Frequency	Operating frequency of the panel	50 Hz	50 Hz, 60 Hz
Rated Current	Maximum current capacity of the AMF panel	100A to 1600A	63A to 3200A
Switching Device	Type of switching device used in the panel	Contactor	Contactor, MCCB, ACB
Control Logic	Logic type for automatic mains failure detection and generator start	Microprocessor-based	Microprocessor-based, PLC-based
Generator Start Time	Time taken to start the generator after mains failure	10-15 seconds	10-30 seconds
Switching Time	Time taken to switch from mains to generator supply	2-5 seconds	1-10 seconds
Control Voltage	Voltage used for the control circuit	230V AC	24V DC, 48V DC, 110V AC, 230V AC
Generator Compatibility	Compatibility with different types of generators	Diesel, Gas Generators	Diesel, Gas, Dual Fuel Generators
Protection Relays	Types of protection relays included	Overload, Short Circuit	Overload, Short Circuit, Earth Fault, Under/Over Voltage
Ingress Protection (IP Rating)	Level of protection against dust and water	IP 42	IP 42, IP 54, IP 55
Panel Structure	Type of panel structure	Floor-mounted, Compartmentalized	Floor-mounted, Wall-mounted, Compartmentalized
Busbar Material	Material used for busbars	Copper	Copper, Aluminum
Busbar Size	Cross-sectional area of the busbar	50mm x 10mm	50mm x 10mm to 100mm x 10mm
Busbar Insulation	Type of insulation for busbars	Heat Shrink PVC Sleeves	PVC Sleeves, Epoxy Coated
Auxiliary Power Supply	Power supply for auxiliary circuits	230V AC	24V DC, 230V AC
Operating Temperature	Ambient temperature range for normal operation	-5°C to +40°C	-10°C to +55°C
Cooling Arrangement	Cooling method used in the panel	Natural Air Cooling	Natural Air, Forced Air Cooling
Compliance Standards	Standards the panel adheres to	IEC 61439	IEC 61439, IS 8623
Cable Entry	Provision for cable entry	Bottom	Bottom, Top

Applications of Auto Mains Failure Panels

AMF boards or AMF panels are essential across various sectors such as in industrial facilities, processing plants, and hospitals, where continuous power is demanded. They support heavy operations in metalworks and textile factories, maintain consistent power in apartment complexes, and are crucial for uninterrupted service in telecommunications, safeguarding critical infrastructure and processes.

AMF Panel Safety and Compliance

AMF panel safety and compliance are crucial to ensuring the reliability and safety of the electrical power system. Our AMF panel design is made to meet strict safety standards and comply with industry regulations. Made from high quality materials, they provide good protection against electrical damage and ensure safety in critical areas in accordance with all required certifications and instructions. Our panels can be relied upon for high performance and compliance with the highest safety regulations.

Trust Burak Electric for AMF Panels

Our AMF products backed by expertise, quality control, and standard certifications. Our AMF control panels are designed with safety and efficiency in mind, ensuring reliable and uninterrupted power supply. With rigorous testing and certification, our products meet international standards, providing you with peace of mind and a long-lasting solution.
